KNURLING
KNURLING TOOLS
Form-Knurling Tools
Con este tipo de herramientas las estrías en la pieza se generan por deformación del material al ejercer las moletas presión sobre la pieza mientras gira. Este método no implica arranque de material por lo que no hay generación de virutas.
Cut-Knutling Tools
Con este tipo de herramientas las estrías en la pieza se generan por corte. Gracias a la posición inclinada de la moleta, estas van cortando el material mientras la pieza gira.
M1
Features
- Recommended for RAA* type knurling
- For non-repetitive works
- HSS pin fixed by circlip
Handle Size (HxW)
- 14×14
- 16×16
Knurl
- 20x8x6
Feasible
forms
RAA*
RBL 30º
RBL 45º
RBR 30º
RBR 45º
RGE 30º
RGE 45º
RGV 30º
RGV 45º
RKE
RKV
M2
Features
- Recommended for RGE* type knurling
- Revolving head for knurls self-centering (Fig. 1)
- For non-repetitive works
- HSS pins
Handle Size (HxW)
- 25×25
Knurl
- 20x8x6
Feasible
forms
RAA
RGE 30º*
RGE 45º*
M3
Features
- Recommended for RGE* type knurling
- Knurls self-centering by threaded spindle
- Double position of the arms for higher
- working capacity (Fig. 1)
- Lower risk of bending the workpiece as tool
- does not make radial pressure
- Suitable for non-repetitive works
- HSS pins fixed by circlip
Handle Size (HxW)
- 25×20
Knurl
- 20x8x6
Feasible
forms
RAA
RGE 30º*
RGE 45º*
M7
Features
- Recommended for RGE* type knurling
- Pivoting head for knurls self-centering (Fig. 1)
- For non-repetitive works
- HSS pins fixed by circlip
Handle Size (HxW)
- 20×18
- 25×18
Moleta
- 20x8x6
Formas
realizables
RAA
RGE 30º*
RGE 45º*
M6
Características
- Recommended for RAA* type knurling
- Carbide pin
- Anti-wearing treatment of the tool surface
- Adjustment of tool clearance angle by threaded studs integrated in the tool shank
Handle Size (HxW)
- 8×8
- 10×10
- 12×12
- 14×14
- 16×16
- 20×20
Knurl
- 10x5x4
- 15x6x4
- 20x6x6
- 20x8x6
- 20x10x6
Feasible
forms
RAA*
RBL 30º
RBL 45º
RBR 30º
RBR 45º
RGE 30º
RGE 45º
RGV 30º
RGV 45º
RKE
RKV
M8
Features
- Recommended for RAA* type knurling
- Carbide pin
- Anti-wearing treatment of the tool surface
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 8×8
- 10×10
- 12×12
Moleta
- 10x4x4
- 10x5x4
- 15x4x4
- 15x5x4
- 15x6x4
Formas
realizables
RAA*
RBL 30º
RBL 45º
RBR 30º
RBR 45º
RGE 30º
RGE 45º
RGV 30º
RGV 45º
RKE
RKV
M20
Features
- Recommended for RAA* type knurling
- For knurling up to a shoulder (Fig.1)
- HSS bushing
- Anti-wearing treatment of the tool surface
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 10×10
- 12×16
- 16×16
Knurl
- 15x6x10/6
Feasible
forms
RAA(*)
RBL 30º
RBL 45º
RBR 30º
RBR 45º
RGE 30º
RGE 45º
RGV 30º
RGV 45º
RKE
RKV
M4
Features
- Recommended for RAA type knurling
- Carbide pin
- Anti-wearing treatment of the tool surface
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 16×20
- 20×20
- 25×20
- 25×25
Knurl
- 20x8x6
- 20x10x6
- 25x8x8
- 25x10x8
- 25x12x8
Formas
realizables
RAA*
RBL 30º
RBL 45º
RBR 30º
RBR 45º
RGE 30º
RGE 45º
RGV 30º
RGV 45º
RKE
RKV
M10
Features
- Recommended for RAA* type knurling
- For knurling up to a shoulder (Fig. 1)
- HSS bushing
- Able to fit on right-hand or left-hand (Fig. 2)
- Anti-wearing treatment of the tool surface
- Adjustment of tool clearance angle by threaded studs integrated in the shank
- Supplied with a HSS hardened washer to
prevent tool wearing
Handle Size (HxW)
- 20×25
- 25×25
Knurl
- 25x10x15/11
Feasible
forms
RAA(*)
RBL 30º
RBL 45º
RBR 30º
RBR 45º
RGE 30º
RGE 45º
RGV 30º
RGV 45º
RKE
RKV
M19
Features
- Recommended for RAA* type knurling
- For internal knurling
- HSS bushing
- Supplied with a HSS hardened washer to
prevent tool wearing
Handle Size (HxW)
- 20×20 / Ø25
- 25×25 / Ø32
Knurl
- 25x10x15/11
Feasible
forms
RAA*
RBL 30º
RBL 45º
RBR 30º
RBR 45º
RGE 30º
RGE 45º
RGV 30º
RGV 45º
RKE
RKV
M15
Features
- Recommended for RKAA* type knurling
- For conical or face knurling
- Swivel tool head (Fig. 1)
- Carbide pin
Handle Size (HxW)
- 12×16
- 16×16
- 20×25
- 25×25
Moleta
- 15x6x4 cónica
- 25x8x8 cónica
- 25x10x8 cónica
- 25x12x8 cónica
Feasible
forms
RKAA*
RKBL 30º
RKBR 45º
M12
Features
- Recommended for RGE* type knurling on small diameter workpieces
- Lower risk of bending the workpiece as tool does not make radial pressure
- Self-centering system to compensate a possible misalignment of the lathe turret (Fig. 2)
- Knurls self-centering by threaded spindle (Fig. 1)
- Carbide pins
- Anti-wearing treatment of the arms surface.
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 8×8
- 10×10
- 12×12
- 16×16
Knurl
- 10x4x4
Feasible
forms
RAA
RGE 30º*
RGE 45º*
M9
Features
- Recommended for RGE* type knurling
- Pivoting head for knurls self-centering (Fig. 1)
- Tool with reversible head able to fit on left-hand or right-hand lathes (Fig. 2)
- Carbide pins
- Anti-wearing treatment surface
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 8×8
- 10×10
- 12×12
- 16×16
Knurl
- 10x4x4
- 15x4x4
Feasible
forms
RAA
RGE 30º*
RGE 45º*
M21
Features
- Recommended for RGE* type knurling
- For knurling up to a shoulder (Fig. 1)
- HSS bushing
- Anti-wearing treatment of the tool surface
- Adjustment of tool clearance angle by threaded studs integrated in the shank
- Supplied with a HSS hardened washer to
prevent tool wearing
Handle Size (HxW)
- 10×10
- 12×16
- 16×16
Knurl
- 15x6x10/6
Feasible
forms
RAA
RGE 30º*
RGE 45º*
M5
Features
- Recommended for RGE* type knurling
- Pivoting head for knurls self-centering (Fig. 1)
- Tool with reversible head able to fit on left-hand or right-hand lathes (Fig. 2)
- Carbide pins
- Anti-wearing treatment surface
- Adjustment of tool clearance angle by threaded
studs integrated in the shank
Tamaño de mango (HxW)
- 20×20
- 25×20
Knurl
- 20x8x6
- 20x10x6
- 25x8x8
- 25x10x8
Feasible
forms
Log in here here to access the Step file, Manual, and Exploded View.
RAA
RGE 30º*
RGE 45º*
M11
Features
- Recommended for RGE* type knurling
- For knurling up to a shoulder (Fig. 1)
- Pivoting head for knurls self-centering (Fig. 2)
- HSS bushings
- Anti-wearing treatment of the tool surface
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 20×20
- 25×20
Knurl
- 25x10x15/11
Feasible
forms
RAA
RGE 30º*
RGE 45º*
M16
Features
- Recommended for RKAA* type knurling
- Specially designed for knurling according to
DIN-72783 - Lower risk of bending the workpiece as tool
does not make radial pressure - Self-centering system to compensate a
possible misalignment of the lathe turret (Fig. 1) - Knurls self-centering by threaded spindle
(Fig. 2) - Carbide pins
- Supplied with HSS hardened washers to prevent arms wearing
Handle Size (HxW)
- Ø25
Knurl
- Cónica
Feasible
forms
RKAA
RKGE 30º*
RKGE 45º*
M22-A
Features
- Recommended for RGE* type knurling on small diameter workpieces
- Lower risk of bending the workpiece as tool does not make radial pressure
- Self-centering system to compensate a possible misalignment of the lathe turret (Fig. 1)
- Knurls self-centering by threaded spindle (Fig. 2)
- Carbide pins
- Anti-wearing treatment of the arms surface
- The position of the arms must be reversed
depending on the Ø to be knurled (Fig. 3)
Handle Size (HxW)
- Ø 19.05 (3/4″)
- Ø 20
- Ø 22
- Ø 25
- Ø 25.4 (1″)
Knurl
- 25x10x8
Feasible
forms
RAA
RGE 30º*
RGE 45º*
M22-B
Features
- Recommended for RGE* type knurling on small diameter workpieces
- Lower risk of bending the workpiece as tool
does not make radial pressure - Self-centering system to compensate a possible misalignment of the lathe turret (Fig. 1)
- Knurls self-centering by threaded spindle (Fig. 2)
- Anti-wearing treatment of the arms surface
- For knurling up to a shoulder (Fig.3)
- The position of the arms must be reversed
depending on the Ø to be knurled (Fig. 4)
Handle Size (HxW)
- Ø 19.05 (3/4″)
- Ø 20
- Ø 22
- Ø 25
- Ø 25.4 (1″)
Knurl
25x10x15/11
Feasible
forms
RAA
RGE 30º*
RGE 45º*
M23-A
Features
- Recommended for RGE* type knurling on small diameter workpieces
- Lower risk of bending the workpiece as tool does not make radial pressure
- Self-centering system to compensate a possible misalignment of the lathe turret (Fig. 1)
- Knurls self-centering by threaded spindle (Fig. 2)
- Carbide pins
- Anti-wearing treatment of the arms surface
- The position of the arms must be reversed depending on the Ø to be knurled (Fig. 3)
Handle Size (HxW)
- 20×25
- 25×25
Knurl
- 25x10x8
Feasible
forms
RAA
RGE 30º*
RGE 45º*
M23-B
Features
- Recommended for RGE* type knurling on small diameter workpieces
- Lower risk of bending the workpiece as tool
does not make radial pressure - Self-centering system to compensate a possible misalignment of the lathe turret (Fig. 1)
- Knurls self-centering by threaded spindle (Fig. 2)
- Anti-wearing treatment of the arms surface
- With B type arms for knurling up to a shoulder (Fig. 4)
Handle Size (HxW)
- 20×25
- 25×25
Knurl
25x10x15/11
Feasible
forms
RAA
RGE 30º*
RGE 45º*
M17 10 / M17 20
Features
- Recommended for RAA* and RGE* type knurling
- Frontal feeding by means of 3 jaws simultaneously adjusted (Fig. 1)
- Self-centering system to compensate a possible misalignment of the lathe turret (Fig. 2)
- Carbide pins
- Anti-wearing treatment of the tool surface
Handle Size (HxW)
- Ø 12.7 (1/2″)
- Ø 16
- Ø 19.05 /3/4″)
- Ø 20
- Ø 22
- Ø 25
- Ø 25.4 (1″)
Moleta
- 10x4x4
- 20x6x6
Feasible
forms
RAA
RGE 30º*
RGE 45º*
M17 15 / M17 25
Features
- Recommended for RAA and RGE* type knurling
- Frontal feeding by means of 3 jaws simultaneously adjusted (Fig. 1)
- Self – centering system to compensate a
misalignment of the lathe turret (Fig. 2) - Carbide pins
- Anti-wearing treatment of the tool surface
- For knurling up to a shoulder (Fig.3)
Handle Size (HxW)
- Ø 12.7 (1/2″)
- Ø 16
- Ø 19.05 /3/4″)
- Ø 20
- Ø 22
- Ø 25
- Ø 25.4 (1″)
Knurl
15x6x10/6
25x10x15/11
Feasible
forms
RAA
RGE 30º*
RGE 45º*
MFS 89
Features
- Recommended for RAA* type knurling
- Pivoting head for knurl alignment (Fig. 1)
- HSS bushing
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 8×8
- 10×10
- 12×12
Knurl
8.9×2.5×4
Feasible
forms
Log in here here to access the Step file, Manual, and Exploded View.
Right – handed R
RAA*
RBR 30º
Left – handed L
RAA*
RBL 30º
MFS1 14
Features
- • Recommended for RAA* type knurling
- Pivoting head for knurl alignment (Fig. 1)
- HSS+TIN bushing
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 12×14
- 14×14
- 16×16
Knurl
14.5x3x5
Feasible
forms
Log in here here to access the Step file, Manual, and Exploded View.
Right – handed R
RAA*
RBR 30º
Left – handed L
RAA*
RBL 30º
MFS 14
Features
- Recommended for RAA* type knurling
- Pivoting head for knurl alignment (Fig. 1)
- Tool with reversible head able to fit on lefthand
or right-hand lathes (Fig. 2) - HSS+TIN bushing
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 12×16
- 14×16
- 16×16
Knurl
14.5x3x5
Feasible
forms
Log in here here to access the Step file, Manual, and Exploded View.
Right – handed R
RAA*
RBR 30º
Left – handed L
RAA*
RBL 30º
MFS 21
Features
- Recommended for RAA* type knurling
- Pivoting head for knurl alignment (Fig.1)
- Tool with reversible head able to fit on lefthand or right-hand lathes (Fig. 2)
- HSS+TIN bushing
- Adjustment of tool clearance angle by
threaded studs integrated in the shank
Handle Size (HxW)
- Ø 19.05 (3/4″) x 25
- Ø 25.4 (1″) x 25
- 20×25
- 25×25
Knurl
21.5x5x8
Feasible
forms
Log in here here to access the Step file, Manual, and Exploded View.
Right – handed R
RAA*
RBR 30º
Versión Izquierda L
RAA*
RBL 30º
MFS 32
Features
- Recommended for RAA* knurlin
- Pivoting head by endless screw, for a precisse knurl alignment (Fig. 1)
- Reversible body for righthand or lefthand tool version (Fig. 2)
- Minimum tool overhang (Fig. 3)
- Maximum rigidity to guarantee an excellent knurling quality.
- Possibility of knurling any helix between 0º-30º (Fig. 4)
Handle Size (HxW)
- 20×25
- 25×25
- 32×32
Knurl
14.5x3x5
Feasible
forms
Log in here here to access the Step file, Manual, and Exploded View.
Right – handed R
RAA*
RBR 30º
Left – handed L
RAA*
RBL 30º
MFS 42
Features
- Recommended for RAA* type knurling
- Pivoting head for knurl alignment (Fig. 1)
- Tool with reversible head able to fit on lefthand or right-hand lathes
- HSS bushing
Handle Size (HxW)
- 40×50
Knurl
21.5x5x8
Feasible
forms
Logueate aquí para poder tener acceso al Step, Manual y Explosión.
Right – handed R
RAA*
RBR 30º
Left – handed L
RAA*
RBL 30º
MF 89
Features
- Recommended for RGE* type knurling
- Easy setting to the workpiece diameter by means of a graduated scale (Fig. 2)
- Pivoting head for knurls self-centering (Fig. 1)
- HSS+TIN bushing
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 8×8
- 10×10
- 12×12
Knurl
8.9×2.5×4
Feasible
forms
Log in here here to access the Step file, Manual, and Exploded View.
RGE 30º*
RGE 45º*
MF1 14
Características
- Recommended for RGE* type knurling
- Easy setting to the workpiece diameter by means of a graduated scale (Fig. 2)
- Tool with reversible shank able to lit on lefthand or right-hand lathes (Fig. 1)
- HSS+TIN bushing
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 12×14
- 14×14
- 16×16
Knurl
14.5x3x5
Feasible
forms
Log in here here to access the Step file, Manual, and Exploded View.
RGE 30º*
RGE 45º*
MF 14
Features
- Recommended for RGE* type knurling
- Easy setting to the workpiece diameter by means of a graduated scale (Fig. 2)
- Pivoting head for knurls self-centering (Fig. 1)
- HSS+TIN bushing
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- 12×16
- 14×16
- 16×16
Knurl
14.5x3x5
Feasible
forms
Log in here here to access the Step file, Manual, and Exploded View.
RGE 30º*
RGE 45º*
MF 21
Features
- • Recommended for RGE* type knurling
- Easy setting to the workpiece diameter by means of a graduated scale (Fig. 2)
- Up & down tool head alignment for knurls
centering (Fig. 1) - Tool with reversible head able to fit on left-hand or right-hand lathes (Fig. 3)
- HSS+TIN bushing
- Adjustment of tool clearance angle by threaded studs integrated in the shank
Handle Size (HxW)
- Ø 19.05 (3/4″) x 25
- Ø 25.4 (1″) x 25
- 20×25
- 25×25
Knurl
21.5x5x8
Feasible
forms
Log in here here to access the Step file, Manual, and Exploded View.
RGE 30º*
RGE 45º*
MF 21 VDI
Features
- Recommended for RGE* type knurling
- Easy setting to the workpiece diameter by means of a graduated scale (Fig. 2)
- Pivoting head for knurl alignment (Fig. 1)
- HSS+TIN bushing
Handle Size (HxW)
- VDI Ø30
- VDI Ø40
Knurl
21.5x5x8
Feasible
forms
Logueate aquí para poder tener acceso al Step, Manual y Explosión.
RGE 30º*
RGE 45º*
MF 42
Features
- Recommended for RGE* type knurling
- Easy setting to the workpiece diameter by means of a graduated scale (Fig. 3)
- Up&down tool head alignment for knurls
centering (Fig. 1) - Tool with reversible head able to fit on left-hand or right-hand lathes (Fig. 2)
- Carbide pins
Handle Size (HxW)
- 43×60
Knurl
42x12x18
Feasible
forms
Logueate aquí para poder tener acceso al Step, Manual y Explosión.
RGE 30º*
RGE 45º*
