Knurling Tools
Las herramientas de moleteado se emplean para generar estrías en las piezas. Existen dos tipos principales de moletreadores: los que operan por deformación (las estrías se forman mediante la aplicación de presión sobre la pieza mientras gira) y los que lo hacen por corte (las estrías se generan gracias a la posición inclinada de la moleta, la cual corta el material mientras la pieza gira.).
-
Knurls
Con este tipo de moleteado las estrías se generan por deformación del material, al ejercer las moletas presión sobre la
-
- Burnishing
- Rotary Broaching
- Knurling
BURNISHING
BURNISHING TOOLS
Rollers Burnishing Tools
Este tipo de herramientas utilizan un rodillo de acero rápido templado o de metal duro.
Diamond Burnishing Tools
Este tipo de herramientas utilizan una punta de diamante de un determinado radio especifico para cada material a bruñir.
HBM 20-E
Features
- Tool designed for burnishing on lathes, on various profiles
- Head provided with an internal spring system that regulates the pressure making it homogeneous in all the workpieces (Fig.1)
- The roller is supported between axial bearings
- Usable on workpieces of different types of materials with hardness up to 45 HRC
- Carbide pin
- Provided with a U type burnishing roller made of HSS and hardened to 62 HRC, with polished surface Ra<0.4
Handle Size (HxW)
- 12×12
- 16×16
- 20×20
Rollers
- RB 20x4x4
Forms
Profile U
HBM 20-B
Features
- Tool designed for burnishing on lathes, on various profiles
- Possibility of burnishing up to one face
- Head provided with an internal spring system that regulates the pressure making it homogeneous in all the workpiece (Fig.1)
- The roller is supported between axial and radial bearing
- Usable on workpieces of different types of materials with hardness up to 45 HRC
- Provided with a B type burnishing roller made of HSS and hardened to 62 HRC, with polished surface Ra<0.4
Handle Size (HxW)
- 12×12
- 16×16
- 20×20
Rollers
- RB 20x11x16/13
Forms
Profile B
HBC 20-E
Features
- Tool designed for burnishing on lathes, on various profiles
- Head provided with an internal spring system that regulates the pressure making it homogeneous in all the workpieces (Fig.1)
- The roller is supported between axial bearings
- Usable on workpieces of different types of materials with hardness up to 45 HRC
- Carbide pin
- Provided with a U type burnishing roller made of HSS and hardened to 62 HRC, with polished surface Ra<0.4
Handle Size (HxW)
- 12×16
- 16×16
Rollers
- RB 20x4x4
Forms
Profile U
HBC 20-B
Features
- Tool designed for burnishing on lathes, on various profiles
- Possibility of burnishing up to one face
- Head provided with an internal spring system that regulates the pressure making it homogeneous in all the parts (Fig.1)
- The roller is supported between axial and radial bearing
- Usable on workpieces of different types of materials with hardness up to 45 HRC
- Provided with a B type burnishing roller made of HSS andhardened to 62 HRC, with polished surface Ra<0.4
Handle Size (HxW)
- 12×16
- 16×16
Rollers
- RB 20x11x16/11
Forms
Profile B
HBU 20
Features
- Tool designed for burnishing on lathes, on various profiles
- Rotating head with graduated scale (Fig.1&2)
- Head provided with an internal spring system that regulates the pressure making it homogeneous in all the workpieces (Fig.1)
- The roller is supported between axial bearings
- Usable on workpieces of different types of materials with hardness up to 45 HRC
- Carbide pin
- Provided with a U type burnishing roller made of HSS and hardened to 62 HRC, with polished surface Ra<0.4
Handle Size (HxW)
- 10×16
- 12×16
- 16×16
Rollers
- RB 20x4x4
Forms
Profile U
HBU 42
Features
- Tool designed for burnishing on lathes, on various profiles
- Rotating head with graduated scale (Fig.1&2)
- The pressure of the head can be adjusted in order to obtain different levels of burnishing on the workpiece (Fig.3)
- The roller is supported between axial bearings
- Usable on workpieces of different types of materials with hardness up to 45 HRC
- Carbide pin
- Provided with a U type burnishing roller made of HSS and hardened to 62 HRC, with polished surface Ra<0.4
Handle Size (HxW)
- 20×25
- 25×25
Rollers
- RB 42x6x10
Forms
Profile U
HBE
Features
- Tool designed for burnishing on lathes, on various profiles
- The roller is supported between axial bearings
- The pressure of the head can be adjusted in order to obtain different levels of burnishing on the workpiece (Fig.1)
- Carbide pin
- Usable on workpieces of different types of materials with hardness up to 45 HRC
- Provided with a E type burnishing roller made of HSS and hardened to 62 HRC, with polished surface Ra<0.4
Handle Size (HxW)
- 25×25
Rollers
- RB 25x6x6
Forms
Profile E
HBB
Features
- Tool designed for burnishing on lathes, on various profiles
- The roller is supported between axial and radial bearings
- The pressure of the head can be adjusted in order to obtain different levels of burnishing on the workpiece (Fig.1)
- Possibility of burnishing up to one face
- Usable on workpieces of different types of materials with hardness up to 45 HRC
- Provided with a B type burnishing roller made of HSS and hardened to 62 HRC, with polished surface Ra<0.4
Handle Size (HxW)
- 25×25
Rollers
- RB 30x13x20/17
Forms
Profile E
HBI 20
Features
- Tool designed for burnishing internal and/or external surfaces
- For burnishing holes from Ø22 mm x 70 mm deep
- Head provided with an internal spring system that regulates the pressure making it homogeneous on all parts
- The roller is supported between axial and radial bearings
• Usable on workpieces of different types of materials with hardness up to 45 HRC - Provided with a B type burnishing roller made of HSS and hardened to 62 HRC, with polished surface Ra<0.4
Handle Size (HxW)
- Ø12
- Ø16
- Ø20
Rollers
- RB 20x11x16/13
Forms
Profile B
HBMD
Features
- Tool designed for burnishing on lathes, on various profiles
- Diamond tip aligned with the top face of the shank
- The head is equipped with an internal spring system to regulate the pressure of the diamond tip, making it homogeneous on all parts (Fig.1)
- Can be used on workpieces made of different types of materials with hardness up to 63 HRC
- Possibility of placing the diamond tip in different positions to extend the life of the tool
Handle Size (HxW)
- 12×12
- 16×16
- 20×20
Diamond
DT 12
Diamond
Tip
References:
• DT 12-R0.4
• DT 12-R0.8
• DT 12-R1.0
• DT 12-R2.0
HBCD
Features
- Tool designed for burnishing on lathes, on various profiles
- Diamond tip aligned with the centre of the shank
- The head is equipped with an internal spring system to regulate the pressure of the diamond tip, making it homogeneous on all parts (Fig.1)
- Can be used on workpieces made of different types of materials with hardness up to 63 HRC
- Possibility of placing the diamond tip in different positions to extend the life of the tool
Handle Size (HxW)
- 12×16
- 16×16
Diamond
DT 12
Diamond
Tip
References:
• DT 12-R0.4
• DT 12-R0.8
• DT 12-R1.0
• DT 12-R2.0
HBUD-P
Features
- Tool designed for burnishing on lathes, on various profiles
- Diamond tip aligned with the top face of the shank
- Rotating head with graduated scale (Fig.1&2)
- The head is equipped with an internal spring system to regulate the pressure of the diamond tip, making it homogeneous on all parts (Fig.3)
- Can be used on workpieces made of different types of materials with hardness up to 63 HRC
- Possibility of placing the diamond tip in different positions to extend the life of the tool
Handle Size (HxW)
- 10×16
- 12×16
- 16×16
Diamond
DT 12
Diamond
Tip
References:
• DT 12-R0.4
• DT 12-R0.8
• DT 12-R1.0
• DT 12-R2.0
HBUD-G
Features
- Tool designed for burnishing on lathes, on various profiles
- Diamond tip aligned with the top face of the shank
- Rotating head with graduated scale (Fig.1&2)
- The head is equipped with an internal spring system to regulate the pressure of the diamond tip, making it homogeneous on all parts (Fig.3)
- Can be used on workpieces made of different types of
materials with hardness up to 63 HRC - Possibility of placing the diamond tip in different positions to extend the life of the tool
Handle Size (HxW)
- 20×25
- 25×25
Diamond
DT 16
Diamond
Tip
References:
• DT 16-R0.4
• DT 16-R0.8
• DT 16-R1.0
• DT 16-R2.0
HBED
Features
- Tool designed for burnishing on lathes, on various profiles
- Diamond tip aligned with the top face of the shank
- The pressure of the head can be adjusted in order to obtain different levels of burnishing on the workpiece (Fig.1)
- Can be used on workpieces made of different types of materials with hardness up to 63 HRC
- Possibility of placing the diamond tip in different positions to extend the life of the tool
Handle Size (HxW)
- 25×25
Diamond
DT 16
Diamond
Tip
References:
• DT 16-R0.4
• DT 16-R0.8
• DT 16-R1.0
• DT 16-R2.0
HBSD 30
Features
- Tool designed for burnishing on lathes, external surfaces of various shapes
- Compact design
- Indexable diamond tip for external tool life
- Tool head supported by an internal preload spring system, for constant pressure on all the parts
- Can be used on different materials with hardness up to 63HRC
Handle Size (HxW)
- 10×10
- 12×12
- 16×16
Diamond
DT 8
Diamond
Tip
References:
• DT 8-R0.4
• DT 8-R0.8
• DT 8-R1.0
• DT 8-R2.0
HBSD 45
Features
- Tool designed for burnishing on lathes, external surfaces of various shapes
- Compact design
- Indexable diamond tip for external tool life
- Tool head supported by an internal preload spring system, for constant pressure on all the parts
- Can be used on different materials with hardness up to 63HRC
Handle Size (HxW)
- 10×10
- 12×12
- 16×16
Diamond
DT 8
Diamond
Tip
References:
• DT 8-R0.4
• DT 8-R0.8
• DT 8-R1.0
• DT 8-R2.0
HBSD 60
Features
- Tool designed for burnishing on lathes, external surfaces of various shapes
- Compact design
- Indexable diamond tip for external tool life
- Tool head supported by an internal preload spring system, for constant pressure on all the parts
- Can be used on different materials with hardness up to 63HRC
Handle Size (HxW)
- 10×10
- 12×12
- 16×16
Diamond
DT 8
Diamond
Tip
References:
• DT 8-R0.4
• DT 8-R0.8
• DT 8-R1.0
• DT 8-R2.0
